When a Design Cannot Be Made
Renders have no physics. A few designs that look perfect on screen cannot exist in metal β and it is better to hear so at CAD than at year three.
Written by the Mapple Gems workshop, Surat Β· Updated 11 October 2026
Short answer
Most refusals come down to not enough metal in a place that needs it β a shank under about 1.8Β mm, prongs too fine to hold a seat, or beads too small to retain a stone. The rest are geometry: a point or corner with nowhere to put a prong, stones set so close there is no metal between them, or a band that can never be resized. A render shows shapes; it does not know that gold is soft and a hand grips things.
Almost every design can be built. A few cannot be built and last, and those are the ones worth naming β because the render looks identical either way.
A CAD render is a drawing of surfaces, and surfaces have no thickness, no softness and no load β which is why a design can be flawless on screen and impossible in gold. On a computer, a prong can be as fine as you like and still hold a stone perfectly, because the stone is not heavy and the prong cannot bend. In metal, gold sits at about Mohs 2.8 and every prong has to be thick enough to take a seat cut into it and still have material left over. Cut a notch into a prong that started too fine and there is nothing behind the notch. The same logic runs through the whole object: a shank thin enough to look delicate on screen flexes on every grip, and that flex travels up and works the settings loose from below. This is the reason a good workshop occasionally says no, and it is a service rather than an obstruction β the failure would not appear for three to seven years, long after everyone had forgotten the conversation. The honest version of the answer always comes with a reason and an alternative: not βwe cannot do thatβ, but βat that thickness the prongs will not hold a seat β here is the same look at a workable dimension.β
The recurring impossibilities
| The request | Why it fails | What works instead |
|---|---|---|
| A very thin shank | Flexes; works settings loose | Taper it β thin look, 1.8 mm base |
| Hair-fine prongs | No metal left after the seat | Fewer, finer-looking claws |
| No prong on a point | The girdle is thinnest there | A V-prong, or an end cap |
| Stones touching, no metal | Nothing to raise beads from | Slightly smaller melee |
| Full eternity, uncertain size | Cannot ever be resized | Three-quarter β looks identical |
| Engraving at the shank base | A resize cuts through it | Centred on the upper interior |
Every row has an alternative, and that is the point. Almost nothing on this list means βyou cannot have that lookβ β it means the look has to be produced a different way.
Thin does not have to mean weak
The commonest request by far is a band that looks delicate. It is entirely achievable, and the trick is that apparent thinness is about the top and the sides, not the base.
A tapered shank is narrowest at the base and broadens toward the head, so it reads fine on the finger while keeping structural depth where the load is β and as a bonus it makes the centre stone look larger and uses less metal. A knife-edge profile reads even finer from above while carrying real thickness underneath.
What we will not do is take the base below about 1.8Β mm for daily wear, because that is where the ring bends. Reshanking is ordinary maintenance and it is how rings reach a century β but it costs more than the extra half-millimetre would have.
Where pavΓ© runs out of room
A render can place stones with no metal between them, because the software does not need any. A setter does: beads are raised from the metal surrounding each stone, so if the stones are touching there is nothing to raise a bead from.
The consequence is visible in wear rather than at delivery. Over-tight pavΓ© loses stones early, and because beads are often shared between two neighbours, a single worn bead affects a pair. The fix is unglamorous: slightly smaller melee, which looks the same at armβs length and gives the setter working room.
The visible evidence of it being done properly is the same as always β look straight down the row in daylight and every table should sit level, with even spacing and no gaps of exposed metal.
Designs that work but should not be ordered
A separate category: buildable, and still the wrong choice for the person asking.
- A high-profile setting for a working hand. It will catch on everything, and profile height is fixed at casting β it cannot be lowered later without a new ring.
- A closed-back gallery on a stone chosen for brilliance. It cannot be cleaned from underneath, and a film on the pavilion is the commonest cause of a stone looking dull.
- A stone-set band planned to sit against a plain one. Stones at Mohs 9 or above cut a groove into gold under 3. A plain spacer band solves it for very little.
- Mixed karats in the same colour in one stack β 14K beside 18K yellow clashes in daylight, and the softer one abrades where they touch.
- A modern brilliant halo around a genuine antique cut, which puts a high-dispersion row around a deliberately calmer stone and makes the centre look dull.
How to have the conversation early
All of this is free to resolve at CAD and permanent afterwards, because anything cast as one body β profile height, gallery architecture, taper, prong placement, total width β is fixed the moment the wax is made.
So ask for the side elevation with the profile height in millimetres, the shank thickness at the base, and confirmation that every point and corner has a prong over it. Those three questions surface almost every problem on this page before it exists.
And if a workshop does say no, ask the sorting question: βis that canβt, or wonβt?β A βcanβtβ should come with a physical reason you can check elsewhere. A reason that changes when you offer more money was never a physical constraint.
Keep reading
Frequently asked questions
Why wonβt a jeweller make my ring as thin as the render?
Because a render has no physics. Below about 1.8Β mm at the base a shank flexes on every grip, and that flex works the settings loose from below. A tapered or knife-edge profile gives the delicate look while keeping depth where the load is.
Can stones be set with no metal showing between them?
Not securely β beads are raised from the metal around each stone, so touching stones leave nothing to raise a bead from. Slightly smaller melee looks the same at armβs length and gives the setter working room.
What can be changed after casting?
Anything that is a separate piece of metal β the stone, the head, the finish, the shank via a reshank. Anything cast as one body cannot change: profile height, gallery architecture, taper, prong placement and total width across the setting.
How do I tell a real constraint from a preference?
Ask βis that canβt, or wonβt?β A genuine constraint comes with a physical reason you can verify elsewhere and an alternative that gives you the same look. A reason that changes when you offer more money was never physical.
